Instructions for Installing Curtains
Please ensure to carefully follow the provided curtain installation instructions, as requirements may differ based on your home or specific window. Alternatively, you can refer to the printed instructions included with your curtains. If you have any queries, feel free to contact us for immediate assistance.
Upon receipt, your curtains will be ready for installation. Before you begin, it’s advisable to check that you have all the necessary parts for assembly. You can identify these parts using the image provided below. The number of parts required may vary depending on the size of your curtain order and track widths. If you discover any missing or insufficient parts, please reach out to us, and we’ll promptly arrange for their supply.
Pre-Installation Checklist
STEP BY STEP
Before starting the installation process, ensure you have the following tools:
-
Power drill
-
Phillips head screwdriver
-
Pencil, notepad, and metal tape measure
-
Spirit level
-
Small step ladder
-
Stud finder (if necessary)
-
Protective eyewear and gloves when drilling into masonry, tile, or metal
-
It's recommended to have a second person available to assist with curtain fitting
Before beginning assembly
-
determine whether your window requires top fix (to the ceiling surface) or face fix (to the wall) installation. This decision should align with your original order information. If there are discrepancies, please contact us for guidance.
-
For face-fitted double curtains, install the rear (block out) curtain closest to the window before the front (sheer) curtain nearest to the interior. This sequence helps distribute the load evenly on the brackets.
Mounting Instructions
STEP BY STEP
Consider the surface you're drilling into:
-
For standard wall surfaces, use the provided 8-gauge, 35mm screws to attach the brackets. If fixing into plasterboard without a stud, acquire wall plugs or hollow wall anchors for stability.
-
Plasterboard/Gyprock: Use a stud finder to locate studs for bracket placement. Then, fasten the brackets into the surface and stud using the provided screws.
-
Brick/Masonry: Drill pilot holes, then use a 6mm masonry drill bit to create 35mm deep holes. Insert 8-gauge wall plugs into the holes and fasten the brackets securely.
Joining Track Sections:
For tracks wider than 2300mm, sections will be supplied separately. Follow these steps to join them:
-
Slide the joiner halfway through one track length.
-
Slide the second track length over the exposed half of the joiner.
-
Apply force as needed to connect the two track segments until they're flush.
Face Fix Curtain Installation:
-
Step 1: - Position two brackets approximately 150mm from each end of the track, ensuring they are level. Fasten these brackets with the provided screws or appropriate ones for your wall surface.
- For plasterboard, ensure brackets are secured to wall studs. If not possible, use wall plugs and suitable screws for plasterboard installation.
- Position any remaining brackets evenly between the end brackets, ideally spaced about 700mm apart. Fasten all brackets securely in place.
- Pro tip: Align the top of the brackets with the topmost point of the drop measurement provided in your order. Loosely fasten screws in the centre of the bracket holes for adjustable positioning.
Please note, a 15mm deduction has already been made from your curtain drop for underslung track mounting, which does not affect bracket fixing points. -
Step 2: - Clip the track into the brackets by securing the back of the track between the metal and plastic clip.
- Secure the track in place with the underside screw.
- Attach the bracket caps over the brackets.
Top Fix Curtain Installation:
Position the first two top fixing clips approximately 150mm from each end of the track, left and right sides, about 80mm forward of the window. Space remaining clips evenly between them, approximately 700mm apart. Whenever possible, screw these clips into studs.
Pro tip: For double curtains, position the front track clips (sheer curtain) about 100mm in front of the rear clips (block out curtain).
Connecting the Hand Wand:
Hanging Your Curtains:
For S-fold curtains, use the attached hooks to loop through the curtain runners inside the track, ensuring even distribution of the waves.
For pinch pleat curtains, use the attached hooks to loop through the curtain runners. Additional runners can be added if needed by unscrewing the end cap of the track.
Pro Tips:
- For smooth movement of the runners, consider applying a small amount of spray lubricant to the inner track area.
- When hanging curtains, start from the stacking side with the edge of the curtain facing the window.
- Ensure all measurements and placements are in line with your original order information to achieve the desired fit and appearance.
